Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE
Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE

Zoom A1 FOUR/A1X FOUR FOR ACOUSTIC GUITAR, SAXOPHONE, TRUMPET, VIOLIN, HARMONICA, ACOUSTIC BASS, AND MORE

Rp 0,00

FEATURES

  • A1 FOUR offers over 80 built-in effects / A1X FOUR offers over 90 built-in effects
  • Dedicated effects for acoustic guitar, saxophone, trumpet, violin, and harmonica
  • Up to 5 effects can be used simultaneously, chained together in any order
  • 50 memory locations for storing user-created patches
  • Looper for recording up to 30 seconds / 64 beats of CD-quality audio with seamless start and end times
  • ZOOM Guitar Lab software for creating, editing and managing effects and patches
  • 68 built-in rhythm patterns tailored for unplugged styles of music can be used in combination with the Looper
  • Onboard chromatic tuner supports all standard guitar tunings, including open and drop tunings
  • Output jack for connection to amp or headphones
  • A1 FOUR and A1X FOUR runs on 4 AA batteries, with alkaline battery life of 18 hours; MAA-1 Requires 2 AA batteries
  • USB port for firmware updates, power and connection to ZOOM Guitar Lab

*Manufacturer names and product names mentioned in this presentation are trademarks or registered trademarks of their respective owners and do not indicate any affiliation with ZOOM CORPORATION.  All product and artist names are intended only to illustrate sonic characteristics that were used as reference in the development of this product.

Popular effects such as Distortion, Chorus and Wah are typically designed to work with the electric guitar. The A1/A1X FOUR provide all-new effects that are engineered to process the unique signals generated by acoustic instruments.

SPECS

A1 FOUR/A1X FOUR

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS 5
USER PATCHES 50
SAMPLING FREQUENCY 44.1 kHz
A/D CONVERSION 24-bit, 128× oversampling
D/A CONVERSION 24-bit, 128× oversampling
SIGNAL PROCESSING 32-bit
DISPLAY 128x32 dot matrix LCD

INPUT

INPUT Standard mono phone jack Rated input level: -20 dBuInput impedance (line): 470 k?
AUX IN Stereo mini jack Rated input level: -10 dBuInput impedance (line): 1k?

OUTPUT

OUTPUT Standard stereo phone jack (combined line/headphone) Maximum output level: Line +2 dBu (10 k? or more output impedance)Headphones 17 mW + 17 mW (32? load)
INPUT S/N 120dB
NOISE FLOOR (RESIDUAL NOISE) -97 dBu
POWER AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 4 AA batteries (about 18 hours continuous operation time when using alkaline batteries with the LCD backlight off)
USB USB MIDI, USB Micro-B Power can also be supplied through the USB port.When using a cable designed only for power, other USB functions cannot be used.
EXTERNAL DIMENSIONS A1 FOUR Height: 156 mm (D) × 130 mm (W) × 42 mm (H)Weight:  340 g (excluding batteries)A1X FOUR   Height:  156 mm (D) × 216 mm (W) × 52 mm (H)Weight:  610 g (excluding batteries)

MAA-1

INPUT INPUT XLR balanced input (2: hot) Input gain: +3 – +30 dBInput impedance: 10 k?Maximum input level: +4 dBu+48V phantom power
OUTPUT Standard mono phone jack Nominal output level: ?20 dBuMaximum output level: +7 dBuOutput impedance: 1 k?
POWER 2 AA batteries Continuous operation time (when phantom current is 3 mA) About 15 hours (using alkaline batteries)?About 15 hours (using nickel metal hydride batteries)
EXTERNAL DIMENSIONS Height:  177 mm (D) × 23 mm (W) × 25 mm (H) Weight : 70 g (excluding batteries)                 0 dBu = 0.775 V
