– New quad-core processor with 3.2 GB of memory
– 180 sounds featuring a selection of the legendary PLATINUM one
– over 100 organ presets
– Unlimited 24-bit/48 kHz polyphony
– 12 independent DSP effects, and independently programmable outputs that can be used individually to route each part
In addition the Bluetooth functionality for MIDI and audio enables convenient wireless control of programs and parameters via an iOS device using the VIVO Editor app. Moreover, the XMURE App offers the ability to play supported along with numerous audio accompaniment styles.
Keyboard TP-100 LR: 88 - Keys Hammer action - Triple contact
Tone Generator Advanced T2L: Sampling and Modelling Technology
Sampling XXL wave size, up to 15 seconds on lower piano notes
Sound Wave Format 24 bit linear - 48 KHz (Internal processing and DSP at 32 bit floating)
Digital Analog Convertion (DAC) 24 bit linear - 48 KHz, Dynamic Range, S/N:106dB
Maximum Polyphony Unlimited with 320 Oscillator
Organ Type TW1, TW2, FARF, VX, PIPE + User1, User2 downloadable from website
Sounds over 100 Organ Preset + 180 Sounds + User downloadable from website
Tone Wheel 9 virtual draw faders on LCD for Tone Wheels
Memory Internal: 81 Unlimited loadable from USB Memory
Wave Memory 3.2 GB fully changable by the user with DEXIBELL and Sound Font format
Keyboard Mode 4 Parts (MAIN, LOWER, COUPLED, PEDAL) + 4 MIDI zones
Touch Sensitivity 7 Types + Fixed
Reverb 24 Types
Effects Rotary, Overdrive, Vibrato/Chorus for Organ + 12 Independent DSP x 17 types (3 x Main, 3 x Coupled, 3 x Lower, 3 x Pedal) using "seamless changes" technology at effect recall
Master Equalizer 3-band Digital Equalizer
Chord Enhancer YES
Controllers FX Encoder x 6 Data Entry/Song Level Encoder x 1 Master Volume Knob Wheel 1 & Wheel 2
Button Assign 2
Players .wav, .aiff, .mp3, in all format, frequency and bit rate
Recorder .wav (48 kHz, 32-bit floating) on USB Memory
Master Tuning 415,4 Hz to 466,1 Hz (adjustable increments of 0,1 Hz)+ 2 Preset (440 Hz, 442 Hz)
Temperament 9 Types
User Temperament YES: 3 User
Rhythm Patterns X MURE APP for i-Phone and i-Pad (FREE) with multitracks audio patterns
Connectors OUTPUT: MAIN Balanced: XLR (LR) MAIN / SUB Unbalanced OUTPUT Jacks (L/MONO, R) 1/4-inch phone type
FOOT 1: Progressive Damper Action Pedal with sympathetic resonance simulation
FOOT 2: Function assignable
FOOT 3: Expression Pedal / Function assignable
FOOT 4: Morphing Pedal / Function assignable
MIDI: IN, OUT, THRU
USB: TO HOST (MIDI & DIGITAL AUDIO IN/OUT), TO DEVICE (MEMORY & MIDI)
AUX IN: 1 jack (stereo mini-jack)
Bluetooth Streaming Audio Input, MIDI BLE 4.2
Display Graphic LCD 128 x 64 dots Organic LED, high contrast type
Speakers 2 Full range x 8.9 cm (3,5 inches)
Rated Power Output 35 W x 2 max @ THD+N < 0>
Volume Level SPL 108.1 dB max
DPS on Amplifier Yes
Dynamic EQ. Yes
3 Band Compres. Yes
Power Consumption STAND BY: < 0>
Dimensions Width 1270 mm - 50" Depth 375 mm - 13,9" Height 126 mm -4,9"
Weight 15,4 Kg - 33,9 lb
Accessories Damper Pedal included
