Alto MIXPACK Express Ultra-Portable Powered PA System

Alto MIXPACK Express Ultra-Portable Powered PA System

350 Watts of continuous power

Lightweight, one-piece design for convenient transport

Two 10” speakers with cables included

Built-in mixer with seven-band graphic EQ and XLR, line and RCA inputs

Integrated Alesis DSP with 24-bit effects including reverb, delay and chorus

TECH INFORMATION

Mixer Section

Microphone/Line Input: Electronically balanced, discrele input configuration

Frequency Response: 10 Hz to 55 kHz, +/-3 dBu

Microphone Input Impedance: 3.9 kO

Line Input Impedance: 10kO

Microphone Input S/N ratio: >94 dBu

Microphone Inputs: Balanced XLR connectors

Line Inputs: Balanced / Unbalanced, 1/4' (6.3 mm) TRS jack connectors

Tape Inputs: Unbalanced RCA jack

Inputs Distortion (THD & N): 0.04% at 0 dBu, 1 kHz

Channel EQ High shelving: +/-15 dB @ 12 kHz Low shelving +/-15 dB @ 80 Hz

Aux Send: 1 with paths for DSP internal section, external DSP section and Monitor Out

DSP Section: 24-bit Hall, Room, Vocal, Plate, Stereo Delay, Reverb + Delay and Reverb + Chorus combinations

Master Section: Master Level knob, 4 LEDs level meter, 7-band graphic output EQ, and DSP Return level

Output Master EQ: 7-band, +/-5 dB @ 63Hz, 160 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 16 kHz

Monitor Section: Master Level knob, 4 LEDs level meter, and 1/4" (6.3 mm) Monitor Out jack

Speaker Section

System Type 2-way coax vented box

Frequency Response 65 Hz - 20 kHz at -10 dB

Spherical horn Coverage 70° H × 70° V

Continuous Power 150 Watts AES Standard

Peak Power 300 Watts Peak

Protection Electronic circuit on driver

Speaker Specification 10" (254 mm) Low Frequency Driver / 2" (50.8 mm) Voice Coil, 1" (25.4 mm) Neodymium High

Input Connectors 1/4" (6.3 mm) mono (TS) jack on each cabinet

Amplifier Section

Output Power 350 Watts (EIAJ)

Impedance 4O

Protections Overload / Short Circuit / Soft Clip Limiter / Thermal Protection Fan Cooling

Standard Package

Two speaker cables

Power cord

One microphone cable

Stands: F-8 or F-3 not include
